There are generally two types of mesh fabrics, one is knitted and the other is carded. Among them, the knitted warp-knitted mesh fabric has the most compact structure and the most stable state. The so-called warp-knitted mesh fabric is a fabric with small mesh holes.

Weaving principle

There are generally two weaving methods for woven mesh: one is to use two sets of warp yarns (ground warp and twisted warp) to twist each other to form a shed and interweave with weft yarns. Using a special twisted heald (also known as semi-heald), sometimes twisted on the left side of the ground warp, one (or three) turns, and then twisted on the left side of the ground warp, or five) After weft insertion, the weft yarn is twisted On the right side of the ground warp, the small mesh holes formed by mutual twisting and interweaving of weft yarns have a stable structure and are called lenos; Inserting a reed tooth can weave a fabric with small holes on the surface of the fabric, but because the mesh structure is unstable and easy to move, it is also called false leno.

Fabric Features

With its unique double-sided design and unique structure in the middle (such as X-90° or "Z", etc.), the warp knitted net presents a six-sided breathable hollow three-dimensional structure (three-dimensional elastic support structure), which has the following characteristics:

1. Has good elasticity and buffer protection.

2. Excellent breathability and moisture permeability (warp knitted mesh fabric adopts x-90° or "Z" structure, double-sided mesh, hexagonal breathable hollow three-dimensional structure, air and water flow freely, forming hot and humid microcirculation air layer).

3. Lightweight and easy to wash.

4. Good softness and wear resistance.

5. Diversified meshes, fashionable styles Mesh shapes are diverse, such as triangle, square, rectangle, rhombus, hexagon, column, etc. Through the distribution of meshes, it can present straight bars, horizontal bars, squares, rhombuses, chain links, Pattern effects such as ripples.

Fabric classification:

1 raschel net

Warp knitted elastic mesh is the most important product on the elastic warp knitting machine, such as elastic hexagonal mesh, diamond elastic mesh, Jonestin, etc., generally interwoven with spandex and nylon, and the content of spandex is more than 10%, so it has a strong Its elasticity, often used as clothing, has strong adhesive force and shape correcting ability.

2 tricot mesh

Trico mesh products are produced on HKS series machines and warp knitting machines. The mesh structure of the warp knitting machine is generally symmetrical from left to right. When weaving, it is symmetrical from left to right or up and down. The same line of symmetrical padding is used between the two lines, which is widely used in Mosquito nets, curtains, lace and other sewing.

fabric application

The warp-knitted mesh is also realized through ingenious cutting, sewing and auxiliary processing. When the warp-knitted mesh is used for clothing, it has sufficient gaps, good moisture permeability, air permeability and temperature regulation functions; It has wide adaptability and can be made into soft and elastic clothing; it has good surface properties, dimensional stability and joint breaking strength; it can be used as lining and fabric for special clothing, warp-knitted spacer fabrics, and safety vests.

Warp knitted mesh has good heat preservation, moisture absorption and quick drying properties. At present, the main applications of warp knitted mesh in leisure sports are: sports shoes, swimming suits, diving suits, sports protective clothing, etc.

Used for sewing mosquito nets, curtains, lace; medical elastic bandages of various shapes; military antennas and camouflage nets.
